Molex 1723161106 Ultra-Fit™ Right Angle PCB Header — 3.50 mm Pitch, Dual Row, 6 Circuits, Through-Hole, Tin (Sn) Plating, Black LCP Housing, Glow Wire Capable. Designed for wire-to-board power connections with a right-angle orientation, PCB retention and locator features, and compatibility with Ultra-Fit™ Receptacle Housings 172258 and 172262. Rated up to 12.0 A per contact and 400 V AC/DC. Tray of 1,000 pieces.
Available in stock — ships within 3 days after payment.
Product overview
| Part number | 1723161106 |
| Series | Molex Ultra-Fit™ 172316 |
| Date code | 22+ |
| Product type | Right angle PCB header, dual row |
| Circuits | 6 (3 per row) |
| Pitch | 3.50 mm |
| Mounting type | Through-hole, right angle |
| Current rating | 12.0 A per contact |
| Voltage rating | 400 V AC (RMS) / DC |
| Contact material | Copper alloy, Tin over Nickel plating |
| Housing material | Liquid Crystal Polymer (LCP), Black |
| Flammability rating | UL 94V-0, Glow Wire Capable |
| Operating temperature | −40°C to +120°C |
| Recommended PCB thickness | 1.60 mm |
| Mates with | Ultra-Fit™ Receptacle Housing 172258, 172262 |
| RoHS compliance | Compliant |
| Packaging | Tray — 1,000 pieces |
| Condition | New in original packaging (OVP) |
Applications
- Wire-to-board power connections in industrial and commercial electronics
- Automotive electronics and lighting systems
- Telecommunications and data equipment requiring robust power headers
- Medical, military, and general-purpose PCB assemblies
Shipping
- Ships within 3 days after payment
- Secure packaging for safe delivery
- Free delivery within Germany
Warranty & compliance
- 12-month warranty included
- Product is fully compliant with EU industry standards
- VAT invoice included with every order
(GPSR (EU) 2023/988): Contact us for Manufacturer/EU Responsible Party product safety contact details.
