Palazzoli 474220 TAIS Interlocked Socket with MCB — 2P+E 16A 230V 6H, wall-mounting, IP66/IP67 with additional IP69 rating. Palazzoli thermosetting resin housing in blue RAL 5015 or grey RAL 7042, with integrated MGT 16A curve C circuit breaker, IK10 impact resistance, and screw terminals accepting up to 25 mm² conductors. Suitable for demanding industrial environments requiring high ingress and mechanical protection.
Available in stock — ships within 24 hours after payment.
Product overview
| Part number | 474220 |
| Product type | TAIS interlocked socket with MCB |
| Poles | 2P+E |
| Rated current | 16A |
| Supply voltage | 230V, 50–60 Hz, 6H |
| Rated insulation voltage | 690V |
| Rated short-circuit current | 6 kA |
| Protection device | MCB 16A curve C |
| Operating category | AC-23A / AC-3, 16A – 250V |
| IP protection | IP66/IP67 + IP69 (IEC 60529) |
| Impact resistance | IK10 (IEC/EN 62262) |
| Insulation class | Class II |
| Manufacturing material | Palazzoli thermosetting resin |
| Colour | Blue RAL 5015 / Grey RAL 7042 |
| Execution | Wall mounting |
| Hole type | M25 |
| Conductor section (Cu) | 0.75–25 mm² |
| Ambient temperature range | -25°C to +50°C |
| Certifications | CE, UKCA, CB IMQ, NYCE Colombia |
| Condition | New — original sealed packaging |
Applications
- Single-phase power distribution in industrial plants, food processing, and wash-down environments requiring IP66/IP67/IP69 protection
- Outdoor and marine installations exposed to heavy rain, water jets, or temporary immersion
- Industrial sites requiring IK10-rated enclosures resistant to mechanical impact
- General-purpose interlocked socket outlets with integrated MCB overcurrent protection in manufacturing and process facilities
Shipping
- Ships within 24 hours after payment
- Secure packaging for safe delivery
- Free delivery within Germany
Warranty & compliance
- 12-month warranty included
- Product is fully compliant with EU industry standards
- VAT invoice included with every order
(GPSR (EU) 2023/988): Contact us for Manufacturer/EU Responsible Party product safety contact details.
